Hydraulic Transmission Jack

Call for best price

(08) 8351 6705

South Australia map icon

Ask about our South Australian Lowest Price Guarantee on all products and servicing.

servicing icon

Servicing Peace of Mind

We offer servicing on this product.
Click here to find out more about our servicing.

Technical Specifications

  • Working Load Limit 500kg
  • Overall Width 1000mm
  • Overall Length 1450mm to 1900mm Adjustable
  • Closed Height 950mm
  • Maximum Height 2050mm
  • Cradle Tilt Forward 30 degrees
  • Cradle Tilt Backward 15 degrees
  • Cradle Tilt Sideways 15 degrees (left and right) horizontal
  • Net Weight 60kg


The RitchTM REN6-500A can be used for under hoist removal of most transmission and gear boxes along with transfer cases on 4 wheel drive vehicles.
  • Extendable front leg for ease of positioning under hoists
  • Large 4 way tilting table complete with adjustable rails and fingers.
  • Suits 4WD transmissions fitted with or without transfer cases.
  • Suitable for engines and transmissions for mid mount vehicles.
  • The length of the base is adjustable for extra stability.
  • The cradle has two way tilt adjustment and is fitted with a safety chain.
  • Powered by a 10,000kg Masada jack.
  • Fabricated in Australia.
  • Parts and service available Australia wide.
